56
Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
QtyGPC07AH-K3NNC3D GPC08AH-K3NNC3D
Product Code CK010020900 CK010021000
1 Membrane 63066036 63066036 1
2 Display Board 30567026 30567026 1
3 Guide blade lever 2 10586015 10586015 1
4 Guide blade 1 10516059 10516059 4
5 Guide blade 2 10516062 10516062 1
6 Front Panel 20006078S 20006078S 1
7 Right side plate 20056112 20056112 1
8 Discharge Tube 03616595 03001300037 1
9 Inhalation Tube 03626591 03001000047 1
10 Compressor and ttings 00106093 00106531 1
11 Overload Protector 00181150 00180259 1
12 Motor sub-assy (utter) 15006032 15006032 1
13 Splash Water Flywheel 10336003 10336003 1
14 Fan Motor 2 1501606202 1501606202 1
15 Castor 24236009 24236009 4
16 Chassis 22226062 22226062 1
17 Water level switch sub-assy 26156045 26156045 1
18 water level switch base 26156041 26156041 1
19 Water Level Switch 45010211 45010211 1
20 Water retaining box 20186259 20186259 1
21 Capillary Sub-Assy 03006524 03006549 1
22 Condenser Assy 01106132 01106132 1
23 Left side plate 20056111 20056111 1
24 Filter sub-assy2 11126071 11126071 1
25 Filter sub-assy1 11126070 11126070 1
26 Remote controlbox 20186094 20186094 1
27 Rear Plate 20056113 20056113 1
28 Evaporator Assy 01006107 01006107 1
29 Electric Box Assy 20106081 01406549 1
30 Ambient Temperature Sensor 390000451 390000451 1
31 Main Board 30137038 30137038 1
32 Capacitor CBB65 33000081 3300008108 1
33 Capacitor CBB61 3301074705 3301074705 1
34 Electric Box Cover 01416013 01416013 1
35 Water Tray 12416009 12416009 1
36 Cover of Propeller Housing 22246086 22246086 1
37 Propeller Housing (upper) 22206044 22206044 1
38 Centrifugal fan 1 10316060 10316060 1
39 Propeller Housing (lower) 22206045 22206045 1
40 Guide blade lever 1 10586015 10586015 1
41 Air Louver 2 10516061 10516061 1
42 Air Louver 1 10516060 10516060 4
43 Fan Motor 1 1501606903 1501606903 1
44 Motor Holder 26156089 26156089 1
45 Rear Grill 01476020 01476020 1
46 Centrifugal fan 2 1031606101 1031606101 1
47 Diversion Circle 10376038 10376038 1
48 Power Cord 4002046431 4002046431 1
49 Remote Controller 30510065 30510065 1
50 Rear Clip 2611601001 2611601001 1
51 Plastic Pipe End 06646017 06646017 1
52 P Phose 0523602203 0523602203 1
53 Joint 26116087 26116087 1
54 Drainage hose 05230013 05230013 1
To Next Page
