Gree GPC07AH-K3NNC3D User Manual

4
Technical Information
Service Manual
Parameter Unit Value
Model GPC09AH-K3NNC5A GPC09AH-K3NNC3D
Product Code CK01001484 CK010023000
Power
Supply
Rated Voltage V
～
220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Cooling Capacity Btu/h 9000 9000
Heating Capacity Btu/h / /
Cooling Power Input W 1000 1010
Heating Power Input W / /
Cooling Power Current A 4.44 4.44
Heating Power Current A / /
Rated Input W 1250 1250
Rated Current A 5.8 5.8
Air Flow Volume(H/M/L) m
3
/h 350/300/250 330/300/250
Dehumidifying Volume L/h 0.95 0.95
EER Btu/w.h 9.00 8.91
COP Btu/w.h / /
SEER / /
HSPF / /
Application Area m
2
12-18 12-18
Climate Type T1 T1
Isolation I I
Moisture Protection IPX0 IPX0
Permissible Excessive Operating Pressure
for the Discharge Side
MPa 3.8 3.8
Permissible Excessive Operating Pressure
for the Suction Side
MPa 1 1.7
Throttling Method Capillary Capillary
Defrosting Method / /
Fuse A 3.15 3.15
Operation Temp
o
C 16~30 16~30
Ambient Temp (Cooling)
o
C 16~35 16~35
Ambient Temp (Heating)
o
C / /
Sound Pressure Level (H/M/L) dB (A) 56/54/52 56/54/52
Sound Power Level (H/M/L) dB (A) 66/64/62 66/64/62
Dimension (WXHXD) mm 300X807X375 300X790X345
Dimension of Carton Box (LXWXH) mm 562X352X835 562X352X825
Dimension of Package (LXWXH) mm 565X355X850 565X355X840
Net Weight kg 27 27
Gross Weight kg 32 31
Refrigerant R410A R410A
Refrigerant Charge kg 0.48 0.48
