72
Maintenance
Service Manual
5.Remove left & right side plate
Remove left side plate: unscrew 7
screws as diagram shown to remove
left side plate.
Remove right side plate: unscrew
7 screws of right side plate to remove it.
6.Remove electric box cover
Unscrew 2 screw to remove the electric
box cover.
Step Procedure
screws
left side plate right side plate
screws
screws
electric box cover
electric box
