Gree GPC07AH-K3NNC3D User Manual

6
Technical Information
Service Manual
Parameter Unit Value
Model GPC07AH-K3NNC4B GPC07AH-K3NNC5B
Product Code CK010018500
CK010018600
CK010018601
Power
Supply
Rated Voltage V
～
220-240 220-240
Rated Frequency Hz 50 50
Phases
1 1
Cooling Capacity Btu/h 7000 7000
Heating Capacity Btu/h / /
Cooling Power Input W 790 790
Heating Power Input W / /
Cooling Power Current A 3.50 3.50
Heating Power Current A / /
Rated Input W 950 950
Rated Current A 4.00 4.00
Air Flow Volume(H/M/L) m
3
/h 330/300/250 330/300/250
Dehumidifying Volume L/h 0.75 0.75
EER Btu/w.h 8.86 8.86
COP Btu/w.h
/ /
SEER / /
HSPF / /
Application Area m
2
10-16 10-16
Climate Type T1 T1
Isolation I I
Moisture Protection IPX0 IPX0
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 3.8 3.8
Permissible Excessive Operating Pressure for
the Suction Side
MPa 1 1
Throttling Method Capillary Capillary
Defrosting Method / /
Fuse A 3.15 3.15
Operation Temp
o
C 16~30 16~30
Ambient Temp (Cooling)
o
C 16~35 16~35
Ambient Temp (Heating)
o
C / /
Sound Pressure Level (H/M/L) dB (A) 54/52/50 54/52/50
Sound Power Level (H/M/L) dB (A) 64/62/60 64/62/60
Dimension (WXHXD) mm 300X800X355 300X807X375
Dimension of Carton Box (LXWXH) mm 562X352X835 562X352X835
Dimension of Package (LXWXH) mm 565X355X850 565X355X850
Net Weight kg 24 24
Gross Weight kg 28 28
Refrigerant R410A R410A
Refrigerant Charge kg 0.43 0.43

Gree GPC07AH-K3NNC3D Specifications

General

Brand	Gree
Model	GPC07AH-K3NNC3D
Category	Air Conditioner
Language	English
