10
Remove the Rubber Plug at the Drainage Port, and fix the Pipe Clip on the right rear side of the unit near
the Drainage Port. Fix the
Pipe Clip with a Screw.
Put the
Drainage Hose into the Drainage Port, and tighten the Screw. Then bind with a Pipe Hook.
Put the
Rubber Plug into the other side of th Drainage Hose, connect it with the Pipe Hook, and then
connect it with the
Pipe Clip.
Drainage Hose Installation
1
2
NOTE: Use the continuous drainage option from the drainage port. Install the drainage
hose before using, otherwise poor drainage will affect the unit.
Drainage Port
Drainage Hose
Drainage Hose
Pipe Hook
Drainage Port
Screw
Pipe Clip
Pipe Clip
Pipe Hook
Rubber Plug
INSTALLATION INSTRUCTIONS
