GREE U-Match 5 SERIES UNIT SERVICE MANUAL
212
Appendices
1. Resistance/Temperature Lists of
Temperature Sensors
1.1 Voltage List of 15 KΩ Temperature Sensors (including odu and
idu temperature sensors)
Temperature (℃)
Resistance (kΩ) Voltage (V)
Temperature (℃)
Resistance (kΩ) Voltage (V)
-20 144 0.311 71 2.523 2.825
-19 138.1 0.323 72 2.439 2.838
-18 128.6 0.345 73 2.358 2.852
-17 121.6 0.362 74 2.28 2.865
-16 115 0.381 75 2.205 2.877
-15 108.7 0.4 76 2.133 2.889
-14 102.9 0.42 77 2.064 2.901
-13 97.4 0.44 78 1.997 2.912
-12 92.22 0.462 79 1.933 2.923
-11 87.35 0.484 80 1.871 2.934
-10 82.75 0.506 81 1.811 2.945
-9 78.43 0.53 82 1.754 2.955
-8 74.35 0.554 83 1.699 2.964
-7 70.5 0.579 84 1.645 2.974
-6 66.88 0.605 85 1.594 2.983
-5 63.46 0.631 86 1.544 2.992
-4 60.23 0.658 87 1.497 3.001
-3 57.18 0.686 88 1.451 3.009
-2 54.31 0.714 89 1.408 3.017
-1 51.59 0.743 90 1.363 3.025
0 49.02 0.773 91 1.322 3.033
1 46.8 0.801 92 1.282 3.04
2 44.31 0.835 93 1.244 3.047
3 42.14 0.866 94 1.207 3.054
4 40.09 0.899 95 1.171 3.061
5 38.15 0.931 96 1.136 3.068
6 36.32 0.965 97 1.103 3.074
7 34.58 0.998 98 1.071 3.08
8 32.94 1.033 99 1.039 3.086
9 31.38 1.067 100 1.009 3.092
10 29.9 1.102 101 0.98 3.098
11 28.51 1.138 102 0.952 3.103
12 27.18 1.174 103 0.925 3.108
13 25.92 1.21 104 0.898 3.114
