Gree GUHD series - Page 188

80DWFK6HULHV'&
,QYHUWHU6HUYLFH0DQXDO
185
NO.
Description
GUHD36NM3CO GUHD36NM3CO GUHD42NM3CO GUHD42NM3CO
QtyCF090W0410 CF090W0411 CF090W0420 CF090W0421
Name of Part Part Code Part Code Part Code Part Code
1 Top Cover '01255009P '01255009P '01255009P '01255009P 1
2 Air Guard '01355204 '01355204 '01355204 '01355204 1
3 Condenser Assy 01125373 '01125392 '01125392 '01125392 1
4 Rear Grill '01475012 '01475012 '01475012 '01475012 1
5 4-way Valve Assy 04145342 '04145748 '04145362 04145748 1
6 4-way Valve '43000338 '43000338 '43000338 '43000338 1
7 Pressure Protect Switch '46020006 '46020006 '46020006 '46020006 1
8 Temperature Sensor '3900028002 '3900028002 '3900028002 '3900028002 1
9 Electronic Expansion Valve '07334194 '07334194 '07334194 '07334194 1
10
Electric Expansion Valve
Sub-Assy
07335263 '07335271 '07335271 '07335271 1
11 Cut-off Valve '07133157 '07133157 '07133157 '07133157 1
12 Cut-off Valve 071302391 071302391 '07133185 071302391 1
13 Right Side Plate Sub-Assy '01305441P '01305441P '01305441P '01305441P 1
14 Handle '26235253 '26235253 '26235253 '26235253 2
15 Valve Support Sub-Assy '01715257P '01715257P '01715257P '01715257P 1
16 Clamp '02145008 '02145008 '02145008 '02145008 1
17 Electrical heater '76518732 '76518732 '76518732 '76518732 1
18
Gas-liquid Separator Sub-
Assy
'07255201 '07255201 '07255201 '07255201 1
19 &RPSUHVVRUDQG¿WWLQJV '00205236 00200008 '00205236 00200008 1
20 Inhalation Tube 1 '04655520 '04655520 '04655520 '04655520 1
21 Retaining Plate Sub-Assy '01845235P '01845235P '01845235P '01845235P 1
22 Chassis Sub-assy '01195244P '01195244P '01195244P '01195244P 1
23 Motor Support Assy '01805396 '01805396 '01805396 '01805396 1
24 Motor Support Sub-Assy '01705111 '01705111 '01705111 '01705111 1
25 Fan Motor '150154516 '150154516 '150154516 '150154516 1
26 Axial Flow Fan '10335010 '10335010 '10335010 '10335010 1
27
Insulated board (cover of
electric box)
'20113003 '20113003 '20113003 '20113003 1
28 Front Side Plate Sub-Assy '01305508 '01305508 '01305508 '01305508 1
29 Cabinet '01435007P '01435007P '01435007P '01435007P 1
30 Front Grill '22415005 '22415005 '22415005 '22415005 1
31 Condenser support plate '01895309 '01895309 '01305064P '01305064P 1
32 Left Side Plate '01795020 '01795020 '01795020 '01795020 1
33 left handle '26235401 '26235401 '26235401 '26235401 1
34 Electric Box Assy '01395956 '01395956 '01395956 '01395956 1
35 Radiator '49018113 '49018113 '49018113 '49018113 1
36 Reactor '43130178 '43130178 '43130178 '43130178 1
37 Main Board '30228806 '30228806 '30228806 '30228806 1
38 Electric Box '26905211 '26905211 '26905211 '26905211 1
39 XY Capacitor '33030013 '33030013 '33030013 '33030013 1
40 Main Board '30224311 '30224311 '30224311 '30224311 1
41 High-frequency transformer '43110030 '43110030 '43110030 '43110030 1
42 Filter Board '30228118 '30228118 '30228118 '30228118 1
43 Relay '44020378 '44020378 '44020378 '44020378 1
44 Terminal Board '42011103 '42011103 '42011103 '42011103 1
45 Capacitor '33010009 '33010009 '33010009 '33010009 1
46 Terminal Board 42011221 42011221 '42011043 '42011221 1
