Service Manual
56
Installation and Maintenance
Above data is subject to change without notice.
NO.
Description
Part Code
QtyGVA24AL-K3NNC7A/I
Product Code CG156N00200
1 Bafe Plate 2611454401 1
2 Left Side Plate Sub-Assy 00013100003 1
3 Top Cover Sub-Assy 20906900008 1
4 Rear Plate Sub-Assy 01304364 1
5 Right Side Plate Sub-Assy 00013000005 1
6 Breakwater Sub-Assy 01364069P 1
7 Evaporator Assy 01100100218 1
8 Protection Cover 20124112 1
9 Air Guard Sub-Assy 00008800006 1
10 SteppingMotor 1521210104 1
11 Air Louver 1 10514120 1
12 Air Louver 2 10514121 1
13 Stepping Motor 15214211 1
14
Guide Louver 1 10514167 3
15 Guide Louver 2 1054420303 1
16 Guide Louver 3 1056420503 1
17 Air Outlet Panel Assy 00801400056 1
18 Front Door Plate Sub-assy 000055000028 1
19 Display Board 300001000198 1
20 Display Sub-Assy 000057000041 1
21 Air Intake Panel Assy 0000410001901 1
22 Filter Sub-Assy 1112423502/1112423401 1
23 Temperature Sensor 3900013711 1
24 Chassis 22224474 1
25 Propeller HousingPress Plate 01364215 6
26 Diversion Circle 10374006 1
27 Propeller Housing Sub-assy 12104226 1
28 Fan Motor 1501420208 1
29 Centrifugal Fan 10314001 1
30 Drainage Pipe Sub-assy 0523543401 5
31 Water Tray Sub-Assy 209041060005 6
32 Terminal Board 420001000004 1
33 Main Board 300002000697 1
34 Electric Box Cover Sub-Assy 01404922 1
35 Electric Box Assy 100002003737 1
36 Cover of pass 01254012 2
37 Connecting Cable 400204058 1
38 Power Cord 4002028801 1
39 Remote Controller 305001000125 1
To Next Page
