Service Manual
62
Installation and Maintenance
NO.
Description
Part Code
QtyGVA48AL-M3NNC7A/O GVA55AL-M3NNC7A/O
Product Code CG156W00300 CG156W00100
1 Front Grill 01473001 01473001 2
2 Cabinet 0143543601 0143543601 1
3 Axial Flow Fan 10338731 10338731 2
4 Fan Motor 1501506705 1501506705 2
5 Motor Support Sub-Assy 01705070 01705070 1
6 Condenser Assy 011002000606 011002060087 1
7 Coping 01255013P 01255013P 1
8 Rear Grill 01475006 01475006 1
9 Electric Box Assy 100002002918 100002002917 1
10 AC Contactor 44010226 44010226 1
11 Jumper 4202300118 4202300119 1
12 Terminal Board 42011103 42011103 1
13 Terminal Board 42010328 42010328 1
14 Capacitor CBB61S 3301074705 3301074705 2
15 Phase Reverse Protector 430055000001 430055000001 1
16 Gas-liquid Separator 07220030 07220030 1
17 4-Way Valve Assy 030152000364 030152000393 1
18 Magnet Coil 4300040022 4300040047 1
19 Inhalation Tube Sub-assy 030010000575 030010000614 1
20 Capillary Sub-assy 030006000537 030006000580 1
21 Handle 26235253 26235253 2
22 Rear Side Plate Assy 01305102 01305102 1
23 Valve Support Sub-Assy 0171500101 0171500101 1
24 Compressor and Fittings 009001000239 009001000249 1
25 Compressor Gasket 009012000001 009012000001 4
26 Electrical Heater 7651873203 7651873203 1
27 Clapboard Assy 000075000005 000075000005 1
28 Chassis Sub-assy 01700000156P 01700000156P 1
29 Front Side Plate Sub-Assy 01305034 01305034 1
30 Drainage Joint 06123401 06123401 1
31 Ambient Temperature Sensor 3900020626 3900020626 1
32 Temperature Sensor 3900012137 3900012137 1
33 Temperature Sensor 3900020723 3900012128 1
34 Main Board 300027000481 300027000481 1
Above data is subject to change without notice.
