2.2 Capacity Variation Ratio According to Temperature
09/12K:(208/230V~)
09/12K:(115V~)
Cooling operation ambient temperature range is 0
o
F~118
o
F.
Heating operation ambient temperature range is -13
o
F~75
o
F.
Cooling operation ambient temperature range is 0
o
F~118
o
F.
Heating operation ambient temperature range is -13
o
F~75
o
F.
0
20
40
60
80
100
120
0514
23
32 41 50 59 68 77 86 95 104 118
Capacity ratio(%)
Outdoor temp. (°F)
Cooling
Conditions
Indoor:DB80°F/WB66.9°F
Outdoor:DB95°F
Indoor air flow:Super High
Pipe length:24.6ft
Heating
Capacity ratio(%)
Outdoor temp. (°F)
0
20
40
60
80
100
120
140
160
-13 -5 0510 17 20 24 324143 47 53 59 64 70 75 78
Conditions
Indoor: DB70°F
Outdoor: DB19.94°F/WB19.04°F
Indoor air flow: Super High
Pipe length: 24.6 ft
Cooling:
Heating:
0
20
40
60
80
100
120
140
0
517233241505767758695 104 113 118
Capacity ratio(%)
Outdoor temp. (°F)
Conditions
Indoor:DB80°F/WB66.9°F
Outdoor:DB95°F
Indoor air flow:Super High
Pipe length:24.6ft
0
20
40
60
80
100
120
140
160
-
13 -5 0510 17 20 24 32 41 43 47 53 59 64 70 75
Conditions
Indoor: DB70°F
Outdoor: DB19.94°F/WB19.04°F
Indoor air flow: Super High
Pipe length: 24.6 ft
Capacity ratio(%)
Outdoor temp. (°F)

Gree GWC Specifications

General

Power Supply	220-240V, 50Hz
Type	Split
Refrigerant	R410A
Features	Auto Restart, Sleep Mode, Turbo Mode
EER (Energy Efficiency Ratio)	3.5
Noise Level	50 dB (Outdoor)
Cooling Capacity	12000 BTU/h
Heating Capacity	12000 BTU/h
Weight	Indoor: 9 kg, Outdoor: 30 kg
