5
Technical Information
Service Manual
Model
4LIV09HP115V1A
Product Code
CB574001600
Power
Supply
Rated Voltage V~ 115
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity Btu/h 9100
Heating Capacity Btu/h 10000
Cooling Power Input W 771
Heating Power Input W 814
Cooling Current A 8.7
Heating Current A 9.2
Rated Input W 1450
Rated Current A 17.5
EER (Btu/h)/W 11.3
COP (Btu/h)/W 12.3
SEER 19.5(SEER)19.5(SEER2)
HSPF 9.8(HSPF)8.6(HSPF2)
Air Flow Volume CFM 353/282/264/229/211/194/158
Dehumidifying Volume Pint/d 1.69
Application Area yd
2
14-22
Indoor Unit
Indoor Unit Model
4LIV09HP115V1AH
Product Code of Indoor Unit
CB574N01600
Fan Type Cross-ow
Fan Diameter Length(DXL) mm Ф94X630
Cooling Speed r/min 1350/1150/1100/1000/950/850/750 1350/1150/1100/1000/950/850/750
Heating Speed r/min 1300/1100/1050/1000/950/850/800
Fan Motor Power Output W 20
Fan Motor RLA A 0.40
Fan Motor Capacitor μF 4
Heater Power Input W 68
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф5
Evaporator Row-n Gap mm 2-1.3
Evaporator Coil Length (LXDXW) mm 634X22.8X266.7
Swing Motor Model MP24HF
Swing Motor Power Output W 1.5
Fuse Current A 3.15
Sound Pressure Level dB (A)
Cooling:41/37/35/33/31/28/26
Heating:41/36/35/34/31/29/27
Sound Power Level dB (A)
Cooling:51/47/45/43/41/38/36
Heating:51/46/45/44/41/39/37
Dimension (WXHXD) inch 32 7/8X10 53/64X7 7/8
Package Carton Dimension (LXWXH) inch 35 1/32X12 61/64X10 15/64
Package Dimension (LXWXH) inch 35 15/64X13 37/64X10 43/64
Net Weight Ib 19.8
Gross Weight Ib 24.3
