Gree GWC09QB-D3DNA6E User Manual

21
21
Schéma des dimensions requises pour l'installation
15 cm minimum
Distance du plafond
Distance du mur
Distance du mur
15 cm minimum
15 cm minimum
250 cm minimum
Distance du plancher
300 cm minimum
Distance sans obstruction
Distance sans obstruction
Distance sans obstruction
Distance sans
obstruction
Drain
Distance sans obstruction
50 cm minimum
30 cm minimum
200 cm minimum
50 cm minimum
30 cm minimum
Distance du mur
Installation dimension diagram
At least 15cm Space to the ceiling
Space to the wall
Space to the wall
At least 15cm
At least 15cm
At least 250cm
Space to the floor
At least 300cm
Space to the obstruction
Space to the obstruction
Space to the obstruction
Space to the
obstruction
Drainage pipe
Space to the obstruction
At least 50cm
At least 30cm
At least 200cm
At least 50cm
At least 30cm
Space to the wall
00708_Owner's manual Lomo_Mise en page 1 15-03-03 14:51 Page26

Gree GWC09QB-D3DNA6E Specifications

General

Brand	Gree
Model	GWC09QB-D3DNA6E
Category	Air Conditioner
Language	English
