Configuration of connecting pipe
1. Standard length of connection pipe
5m, 7.5m, 8m.
2. Min. length of connection pipe is 3m.
3. Max. length of connection pipe and max. rising difference.
Cooling
capacity
Max length
of connection
pipe
Max rising
difference
20 10
9000Btu/h
(2637W)
20 10
12000Btu/h
(3516W)
25 10
18000Btu/h
(5274W)
24000Btu/h
(7032W)
Cooling
capacity
Max length
of connection
pipe
Max rising
difference
25 10
30 10
30 20
28000Btu/h
(8204W)
36000Btu/h
(10548W)
30 20
42000Btu/h
(12306W)
30 20
48000Btu/h
(14064W)
Configuration des tuyaux de raccordement
1. Longueur normale du tuyau de raccordement: 5m, 7,5m 8m.
2. Longueur minimum du tuyau de raccordement: 3m.
3. Longueur maximum du tuyau de raccordement et évation maximum.
Capacité de
climatisation
Longueur
max. du tuyau
de raccord
Élévation
max.
20 10
9000Btu/h
(2637W)
20 10
12000Btu/h
(3516W)
25 10
18000Btu/h
(5274W)
24000Btu/h
(7032W)
Capacité de
climatisation
Longueur
max. du tuyau
de raccord
Élévation
max.
25 10
30 10
30 20
28000Btu/h
(8204W)
36000Btu/h
(10548W)
30 20
42000Btu/h
(12306W)
30 20
48000Btu/h
(14064W)
