Installation and Maintenance
Service Manual
Step Procedure
10. Remove Electric Box Assy
Remove screws fixing the electric box subassembly;
loosen the wire bundle and unplug the wiring terminals.
Then lift the electric box to remove it.
11. Remove isolation sheet
Remove the screws xing the isolation sheet and then
remove the isolation sheet.
12. Remove 4-way valve assy and cut-off valve
Unsolder the welding joints connecting the 4-way valve
assy and cut-off valve, remove the 4-way valve and cut-
off valve.
Note:
Before unsoldering the welding joint, wrap the 4-way
valve with a wet cloth completely to avoid damage to
the valve caused by high temperature.
Electric Box Assy
isolation sheet
4-way valve
