Technical Information
Service Manual
Outdoor
Unit
Outdoor Unit Model GWH18ALD-K6DNA1A/O
Outdoor Unit Product Code CB513W01600
Compressor Manufacturer ZHUHAI LANDA COMPRESSOR CO.,LTD
Compressor Model FTz-AN108ACBD
Compressor Oil FW68DA or equivalent
Compressor Type Rotary
Compressor LRA. A 19
Compressor RLA A 4.4
Compressor Power Input W 952
Compressor Overload Protector /
Throttling Method Capillary
Set Temperature Range ºC 16~30
Cooling Operation Ambient
Temperature Range
ºC -15~43
Heating Operation Ambient
Temperature Range
ºC -15~24
Condenser Form
Aluminum Fin-copper
Tube
Condenser Pipe Diameter mm Φ7
Condenser Rows-n Gap mm 1-1.4
Condenser Coil Length (LXDXW) mm 700×38.1×528
Fan Motor Speed rpm 900
Output of Fan Motor W 30
Fan Motor RLA A 0.40
Fan Motor Capacitor μF /
Heater Power Input W
/
Outdoor Unit Air Flow Volume m
3
/h 1950
Fan Type Axial-ow
Fan Diameter mm Φ400
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Permissible Excessive Operating
Pressure for the Discharge Side
MPa 4.3
Permissible Excessive Operating
Pressure for the Suction Side
MPa 2.5
Sound Pressure Level (H/M/L) dB (A) 55/-/-
Sound Power Level (H/M/L) dB (A) 63/-/-
Dimension(WXHXD) mm 732X555X330
Dimension of Carton Box (LXWXH) mm 791X373X590
Dimension of Package(LXWXH) mm 794X376X615
Net Weight kg 26.5
Gross Weight kg 29
Refrigerant R32
Refrigerant Charge kg 0.75
Connection
Pipe
Connection Pipe Length m 5
Connection Pipe Gas Additional Charge g/m 16
Outer Diameter Liquid Pipe inch 1/4
Outer Diameter Gas Pipe inch 3/8
Max Distance Height m 10
Max Distance Length m 25
Note: The connection pipe applies metric diameter.
The above data is subject to change without notice. Please refer to the nameplate of the unit.
