55
Technical Information
Service Manual
1
2
3
4
5
6
7
8910 11 12 13
GWH18AFD-K6DNA2I/O
No. Name No. Name
1 Earthing wire 8 Outdoor fan
2 Live wire 9 DRED(Reserved)
3 Neutral wire 10 Electronic expansion valve
4 Communication wire 11 Compressor Overload
5 4-way valve 12 Temperature sensor
6 Electric heating of chasssis 13 Compressor
7 DRED-DC(Reserved)
