Installation and Maintenance
Service Manual
NO.
Description
Part Code
QtyGWH12MB-K3DNA3K/O
Product Code CB171W07700
1 Front Grill 22413027 1
2 Cabinet Sub-assy 01433062 1
3 Axial Flow Fan 10333004 1
4 Chassis Sub-assy 02803151P 1
5 Clapboard Sub-Assy 01233385 1
6 Drainage Connecter 06123401 1
7 Compressor and Fittings 00103896G 1
8 4-Way Valve Assy 03073151 1
9 Valve Support 0171314201P 1
10 Cut off Valve Assy 07133804 1
11 Valve 07100003 1
12 Valve Support Block 26113017 2
13 Right Side Plate Sub-Assy 0130317801 1
14 Big Handle 26233433 1
15 Electric Expansion Valve Sub-Assy 07133830 1
16 Magnet Coil 4300876701 1
17 Rear Grill 01473009 1
18 Electric Box 20113014 1
19 Filter Board 30033082 1
20 Main Board 30148803 1
21 Electric Box Assy 02613540 1
22 Top Cover Sub-Assy 01253073 1
23 Condenser Assy 01163924 1
24 Motor Support 0170310401 1
25 Fan Motor 1501308502 1
26 Small Handle 26233100 1
Above data is subject to change without notice.
