Installation and Maintenance
Service Manual
11.2 Removal Procedure of Outdoor Unit
ProcedureSteps
1. Before disassembly
3. Remove top cover
2. Remove big handle
top cover
big handle
big handle and then remove it.
Remove connection screws connecting
the top panel with the front panel and the
right side plate, and then remove the top
panel.
To Next Page
