89
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
QtyGWH12QB-K3DNE2D/I GWH12QB-K3DNA5D/I
Product Code CB462N00200 CB425N07001
1 Front Panel 200003000011S 2002267001 1
2 Filter Sub-Assy 11122219 11122219 2
3 Display Board 3056504301 30565260 1
4 Front Case Assy 00000200040 2002249501 1
5 Guide Louver 1051276301 1051272202 1
6 Helicoid Tongue 26112508 26112508 1
7 Left Axile Bush 10512037 10512037 1
8 Rear Case assy 20162010 20162010 1
9 Drainage Hose 0523001408 0523001408 1
10 Ring of Bearing 26152022 26152022 1
11 O-Gasket sub-assy of Bearing 7651205102 7651205102 1
12 Evaporator Supper 2 24212180 24212180 1
13 Cold Plasma Generator / 1114001603 /
14 Evaporator Assy 0100200004407 0100200004406 1
15 Wall Mounting Frame 01252043 01252043 1
16 Cross Flow Fan 10352059 10352059 1
17 Fan Motor 150120874 150120874 1
18 Connecting pipe clamp 2611216401 2611216401 1
19 Rubber Plug (Water Tray) 76712012 76712012 1
20 Stepping Motor 1521212901 1521212901 1
21 Crank 73012005 73012005 1
22 Electric Box Assy 10000205031 10000205063 1
23 Axile Bush 10542036 10542036 1
24 Terminal Board 42011233 42011233 1
25 Jumper 4202021911 4202021903 1
26 Main Board 30145095 30145096 1
27 Screw Cover 2425203001 2425203001 1
28 Electric Box Cover Sub-Assy 0140206501 0140206501 1
29 Shield Cover of Electric Box Cover 01592150 01592150 1
30 Electric Box Cover 20112207 20112207 1
31 Connecting Cable / / /
32 Connecting Cable 4002052317 4002052317 0
33 Remote Controller 30510474 30510474 1
34 Detecting plate(WIFI ) 30110154 30110154 1
To Next Page
