Gree GWH12YD-S6DBA2A/I

34
Installation and Maintenance
Service Manual
8. Installation
8.1 Installation Dimension Diagram
Space to the ceiling
Space to the wall
At least 5 7/8
At least 5 7/8
At least 5 7/8
At least 98 7/16
Space to the wall
Space to the obstruction
Space to the floor
Space to the obstruction
Drainage pipe
Space to the wall
Space to the obstruction
Space to the obstructio
Space to the obstruction
At least 118
At least 19 11/16
At least 78 5/8
At least 11 13/16
At least 11 13/16
At least 19 11/16
