Installation and Maintenance
Service Manual
11.2 Removal Procedure of Outdoor Unit
1. Before disassembly
Remove the screws connecting top cover, left and
right side plate, as well as panel, to remove the top
cover.
2. Remove top cover
top cover
Remove the screws connecting handle and right side
plate, to remove the handle.
3. Remove handle
handle
To Next Page
