Technical Information
Service Manual
Outdoor Unit
Model of Outdoor Unit GWH24YE-S6DBA2A/O
Outdoor Unit Product Code CB466W00300
Compressor Manufacturer/Trademark ZHUHAI LANDA COMPRESSOR CO., LTD
Compressor Model QXFT-D20zF030
Compressor Oil FW68DA
Compressor Type Rotary
L.R.A. A 30
Compressor RLA A 16
Compressor Power Input W 2050
Overload Protector /
Throttling Method Electron expansion valve
Operation Temp
o
C 16~30
Ambient Temp (Cooling)
o
C -18~52
Ambient Temp (Heating)
o
C -30~24
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter mm Ф7
Rows-n Gap mm 3-1.5
Coil Length (LXDXW) mm 994X57.1X748
Fan Motor Speed rpm 820
Output of Fan Motor W 90
Fan Motor RLA A 0.65
Fan Motor Capacitor μF /
Air Flow Volume of Outdoor Unit m
3
/h 4000
Fan Type Axial-ow
Fan Diameter mm Ф550
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Permissible Excessive Operating
Pressure for the Discharge Side
MPa 4.3
Permissible Excessive Operating
Pressure for the Suction Side
MPa 2.5
Sound Pressure Level (H/M/L) dB (A) 58/-/-
Sound Power Level (H/M/L) dB (A) 69/-/-
Dimension (WXHXD) mm 1003X790X427
Dimension of Carton Box (LXWXH) mm 1080X485X840
Dimension of Package (LXWXH) mm 1083X488X855
Net Weight kg 65
Gross Weight kg 70
Refrigerant R32
Refrigerant Charge kg 2.0
Connection
Pipe
Length m 7.5
Gas Additional Charge g/m 40
Outer Diameter Liquid Pipe mm Ф6
Outer Diameter Gas Pipe mm Ф16
Max Distance Height m 30
Max Distance Length m 50
Note: The connection pipe applies metric diameter.
The above data is subject to change without notice; please refer to the nameplate of the unit.
