Gree JKFD15QSR/Na-M

GREE Air-ccoled Closed Control Unit Service Manual
7
Net Weight
kg 71
Connection
pipe
Liquid Refrigerant
mm×pcs
Φ9.52×1
Gas Refrigerant Pipe mm×pcs
Φ12×1
Method of Connection Flared-fitting Joint
Form 2
Class Item
Model
Unit
JKFD7CR/Na-M JKFD7QSR/Na-M
Code of Product EJ13000490 EJ13000450
Characteristics of Units
Total Cooling Capacity /
Sensible Cooling
Capacity(22℃/50%)
kW 6.8/5.8
Total Cooling Capacity /
Sensible Cooling
Capacity(24℃/17℃)
kW 7.2/6.5
Total Cooling Capacity /
Sensible Cooling
Capacity(24℃/45%)
kW 7.0/6.3
Total Cooling Capacity /
Sensible Cooling
Capacity(26℃/50%)
kW 7.3/6.6
Heating Capacity kW 2.7
Rated Humidifying
Ca
p
acit
y
kg/h 4
Air Flow Volume m
3
/h 1950 1950
External Static Pressure Pa 0 15
Acoustic Noise of Indoor
Units
dB(A) 63 55
Range of Temp. Controlling and
Precision
17～28℃±1℃
Range of Humidity and Precision 40～60%±5%
Power Supply 220V～ 50Hz
Coolin
g
Syste
m
Compressor Type Hermetic Scroll Type
Evaporator Type Inner Screw Thread Pipe with Hydrophilic Film Aluminum Fin
Condenser Type Inner Screw Thread Pipe with Hydrophilic Film Aluminum Fin
Refrigerant R410A
Throttling Method Electronic Expansion Valve
Air
Supply
Syste
m
Indoor Unit
Fan
Type Low Noise and Centrifugal External-rotor
Type of
Direct Drive
Air Filter Type Plate Filter (G4)
Heatin
g
Syste
Heater Type Electric Heating
Humidi
fying
Syste
m
Humidifier
Type
Infrared Type
Control Mode
Automatic Control by Mainboard
Indoor
Unit
Indoor Unit Model
JKFD7CR/Na-M(I) JKFD7QSR/Na-M(I)
Dimension
W mm
800 800
D mm
700 700
H mm
2250 1950
Net Weight kg
257 237
Outdoo
r Unit
Outdoor Unit Model
JKFD7P/Na-E(O)
Qty Set
1
Condensing
Fan
Type Low Noise Axial Type
Type of Drive Direct Drive
Noise dB(A) 60
Dimension
W mm
900
D
mm 412
