Gree JKFD15QSR/Na-M

GREE Air-ccoled Closed Control Unit Service Manual
8
H
mm 1350
Net Weight
kg 71
Conne
ction
pipe
Liquid Refrigerant Pipe mm×pcs
Φ9.52×1
Gas Refrigerant Pipe mm×pcs
Φ12×1
Method of Connection Flared-fitting Joint
Form 3
Class Item
Model
Unit
JKFD15CR/Na-M JKFD15QSR/Na-M
Code of Product EJ13000500 EJ13000460
Characteristics of Units
Total Cooling Capacity /
Sensible Cooling
Capacity(22℃/50%)
kW 14.8/13.5
Total Cooling Capacity /
Sensible Cooling
Capacity(24℃/17℃)
kW 15.0/13.6
Total Cooling Capacity /
Sensible Cooling
Capacity(24℃/45%)
kW 14.9/13.8
Total Cooling Capacity /
Sensible Cooling
Capacity(26℃/50%)
kW 16.6/15.0
Heating Capacity kW 5.8 7
Rated Humidifying
Ca
p
acit
y
kg/h 4 4
Air Flow Volume m
3
/h 3700 4800
External Static Pressure Pa 0 75
Acoustic Noise of Indoor
Units
dB(A) 64 62
Range of Temp. Controlling and
Precision
17～28℃±1℃
Range of Humidity and Precision 40～60%±5%
Power Supply 380V 3N～ 50Hz
Coolin
g
Syste
m
Compressor Type Hermetic Scroll Type
Evaporator Type Inner Screw Thread Pipe with Hydrophilic Film Aluminum Fin
Condenser Type Inner Screw Thread Pipe with Hydrophilic Film Aluminum Fin
Refrigerant R410A
Throttling Method Electronic Expansion Valve
Air
Supply
Syste
m
Indoor Unit
Fan
Type Low Noise and Centrifugal External-rotor
Type of
Direct Drive
Air Filter Type Plate Filter (G4)
Heatin
g
Syste
Heater Type Electric Heating
Humidi
fying
Syste
Humidifier
Type
Infrared Type
Control Mode
Automatic Control by Mainboard
Indoor
Unit
Indoor Unit Model
JKFD15CR/Na-M(I) JKFD15QSR/Na-M(I)
Dimension
W mm
980 980
D mm
950 950
H mm
2250 1950
Net Weight kg
380 348
Outdoo
r Unit
Outdoor Unit Model
JKFD15P/Na(O)
Qty Set
1
Condensing
Fan
Type Low Noise Axial Type
Type of Drive Direct Drive
Noise dB(A) 64
Dimension
W mm
1400
D
mm 715
