GREE Air-ccoled Closed Control Unit Service Manual
24
◆Outline Dimension of Indoor Units of JKFD25 Series (Top Air Outlet)
Back SideFront Side
Right Side
◆Outline Dimension of Indoor Units of JKFD25 Series (Bottom Air Outlet)
Back SideFront Side
Right Side
