GREE Air-ccoled Closed Control Unit Service Manual
25
◆Outline Dimension of Indoor Units of JKFD40 Series (Direct Air Supply)
810
2480
2250
Right Side
Front Side Back Side
◆Outline Dimension of Indoor Units of JKFD40 Series (Top Air Outlet)
810
2480
1950
Right Side
Front Side Back Side
