GREE Air-ccoled Closed Control Unit Service Manual
30
◆Top Air Intake and Bottom Air Discharge
Ground
Bracket
Dischange Air
Return Air
Ceiling
Wall Face
Facade
> 600
Separator
> 800
> 600
> 800
> 1000
Wall Face
Wall Face Wall Face
6.3.2 Installation of Outdoor Unit
◆ Disassembly of Outdoor Unit
Local Room of
Components
M6 (24 sets)
Nut with Washer
M6 (16)
Support Leg (4)
Bracket (4)
