GREE Air-ccoled Closed Control Unit Service Manual
129
◆ Parts' list of JKFD25SX2/Na-M(I)
No. Part Name Material Code Q’ty
1 Column (lower) 01853777P 4
2 Electric control door 01393753P 1
3 Mounting plate of electric part 01323785 1
4 Panel 01543800 4
5 Cross beam(middle) 01883704P 2
6 Touch screen ZE130 35018017 1
7 Pressure difference switch2 01325237 1
8 Upper column 01853744P 4
9 Evaporator 01023728 1
10 Left panel 01543858 1
11 Column 01853738 2
12 Upper longitudinal beam 01873782 1
13 Cross beam(strainer) 01883703P 2
14 Longitudinal beam(strainer) 01873789P 2
15 Primary strainer assy 07413715 2
16 Top panel 01263733 1
17 Connection pipe 2 05033765 1
18 Electronic expansion valve 2 07333734 1
19 Column sub-assy (right rear) 01853740P 1
20 Rear electric control plate 02223766 1
21 Air-return pipe2 04673739 1
22 Fixing beam 3 01873786P 1
23 Isolation sheet 01243734P 1
24 Hot gas bypass valve sub-assy 07333730 2
25 Column (fixing beam) 01853739P 1
26 Right door plate 02223764P 1
27 Discharge pipe1 04633744 1
28 Air-return pipe1 04673738 1
29 Strainer 1 07413717 1
30 Strainer 2 07413718 1
31 Cut-off valve 1 07333749 2
32 Cut-off valve 2 07333750 2
33 Discharge pipe2 04633745 1
34 Installation beam of compressor 01873787P 2
35
Compressor and fittings
ZP61KCE-TFD-522
00205272 2
36 Water tray(base) 01283763P 1
37 Column sub-assy (right front) 01853742P 1
38 Fixing bea 2 01873785P 1
39 Fixing bea 1 01873784P 1
