GREE Air-ccoled Closed Control Unit Service Manual
131
8 Column (middle) 01853767P 4
9 Panel (front middle) 01543803 1
10 Cross beam(up) 01873810P 2
11 Longitudinal beam (left) 01873812 3
12 Column (upper) 01853765P 4
13 Column (left) 01853768P 2
14 Centrifugal fan 150184066 2
15 Left panel 01643727 1
16 Evaporator 01023727 1
17 Top panel 01263744 1
18 Top panel2 01263740 1
19 Rear panel 01643726 2
20 Nozzle sub-assy 05033839 1
21 Midddle panel 01643701 1
22 Rear electric control plate 02223767 1
23 Mounting rack of fan 01323775P 4
24 Right door plate 02223764P 1
25 Support sub-assy 01893775 2
26
Electric heater BKR
4500W/380V
32103713 1
27
Compressor and fittings
ZP83KCE-TFD-522
00202231 2
28
Electrode humidifier
KUE0202000
07493701 1
29 Column sub-assy (right rear) 01853759P 1
30 Discharge pipe2 04633741 1
31 Isolation sheet 01243744P 1
32
Column sub-assy
（front right）
01853753 1
33 Air-return pipe2 04673752 1
34 Soleplate 1 of evaporator 01093734P 1
35 Connection pipe 2 05033713 1
36 Fixing beam 3 01873786P 1
37 Installation beam of compressor 01873787P 2
38 Column (fixing beam) 01853739P 1
39 Hot gas bypass valve sub-assy1 - 2
40 Sealing plate 1 01343771P 1
41 Air-return pipe1 04673751 1
42 Sealing plate 2 01343770P 1
43 Discharge pipe1 04633740 1
44 Valve 07303703 1
45 Fixing bea 1 01873784P 1
46 Fixing bea 2 01873785P 1
47 Liquid inlet pipe sub-assy 1 04323852 1
