(3) The pipe should not be bent too much or it may crack. Use a pipe bender when
bending the pipe.
(4) Use a sponge to wrap the uninsulated connection pipe and the joint. Then tie it tight
with a plastic tape.
5 Wire Connection
WARNING!
Before obtaining access to terminals, all supply circuits must be disconnected.
(1) For personal safety, the air conditioner must be properly grounded.
(2) Read carefully the voltage indicated on the nameplate before connecting wires. Then
connect wires according to the wiring diagram. Improper wiring will lead to abnormal
operation or damage the unit.
(3) Power capacity should be large enough. Sectional area of room wires should be
above 2.5mm
2
.
(4) For unit's power supply, please use specialized branch circuit and specialized power
socket.
(5) All wiring must comply with standards to ensure safe and correct operation.
(6) Install specialized branch circuit breaker according to related laws and regulations and
electrical standards.
(7) All wiring must use pressure terminal or single wire. Multi-twisted wire that connects
directly to the wiring board may cause fire hazard.
(8) Keep the wires away from refrigerant pipe, compressor and fan.
(9) Do not alter the inner wires of air conditioner. Manufacturer does not assume
responsibility for damage or abnormal operation due to this reason.
(10) If the unit is installed in places with strong electromagnetic interference, it's
recommended to use twin-twisted shield wire. During wire connection, please pay
attention that the metal shield layer of the twin-twisted wire must be grounded (outer
case) in order to prevent the unit from electromagnetic interference.
(11) Communication line should be separated from the power cord and the connecting wire
of IDU and ODU.
(12) If the project needs higher static pressure, you can set it through the wired controller.
5.1 Connection of Wire and Wiring Board Terminal
(1) Connection of Single Branch Line (shown in Fig 5.1)
1) Use a wired stripper to strip away about 25mm of the insulation layer at the end of
single branch line so that the single-core wire can be exposed.
2) Use a screwdriver to remove the terminal screw on the terminal board.
3) Use a plier to bend the end of single branch line until it forms a circle that has a
similar size with the screw.
4) Lead the screw across the circle of the single branch line and fix it on the wiring
board.
To Next Page
