DecIDIng Where to locate your pellet applIance:
1. Check the “Clearances to Combustibles” section for proper spacing.
2. Do not obtain combustion air from an attic, garage or any unventilated space. Combustion air
may be obtained from a ventilated crawl space.
3. Do not install the stove in a bedroom.
4. You can vent the stove through an exterior wall behind the unit or connect it to an existing
masonry or metal wood stove chimney (must be lined if the chimney is over 6” (15 cm) diameter,
or over 28 inches² (180 cm²) cross sectional area). An interior vent can be used with approved
pipe passing through the ceiling and roof.
5. Locate the stove in a large and open room that is centrally located in the house. This will
optimize heat circulation.
6. The power cord is 8 feet (2.43 m) long and may require a grounded extension cord to reach the
nearest electrical outlet.
7. Stove must sit on a non-combustible pad that extends six inches in front of the door or the
included hearth pad (GF40-025).
removIng your pellet Stove from the crate
1. Start by removing the crating and unit bag, you will need a pry bar and hammer to remove the
crating. A sawzall can be used to remove the crating by cutting the staples.
2. Open or Remove the outer door for easy access to screws securing unit to pallet.
3. Loosen/remove six T-20 screws securing Back Grill, once loose slide downwards and remove.
4. Use a 7/16 wrench or socket to remove the three shipping bolts holding the unit to the pallet,
see Figure 1.
Figure 1: Shipping Bolt Removal
Tools Required:
-T-20 screwdriver or drill bit
-7/16” Wrench or Socket
10 | GF40 Freestanding Pellet Stove
|
