479870 • USF, Rev. 9, March 2020 Copyright 2020 © Greenheck Fan Corporation24
®
Phone: 715.359.6171 • Fax: 715.355.2399 • Parts: 800.355.5354 • E-mail: gfcinfo@greenheck.com • Website: www.greenheck.com
As a result of our commitment to continuous improvement, Greenheck reserves the right to change specifications
without notice.
Specific Greenheck product warranties are located on greenheck.com within the product area tabs and in the
Library under Warranties.
Our Commitment
AMCA Publication 410-96, Safety Practices for Users and Installers of Industrial and Commercial Fans, provides additional
safety information. This publication can be obtained from AMCA International, Inc. at www.amca.org.
Installation / Start-up Checklist
Initial Unit Check
Inspect fan for damage
Verify supply line voltage matches unit
All fan accessories are together
All bolts are tight
Check for debris or standing water in fan
interior
Check all piping and wiring penetrations for
water tightness
Fan Wheel
Radial gap checked
Wheel overlap checked
Wheel centered
Wheel rotates freely
Wheel re-checked 24 hours after install
Bearings
Bearings are aligned
Bearings are properly greased
Setscrews are tight (if equipped)
Mounting bolts are tight
Lube Lines
Lube lines are properly filled with grease
Lube line connections are tight
V-Belts
V-belt drives are properly aligned
Sheaves are tight
Belt tension is correct
Motor mounting bolts are tight
Belt tension checked 24 hours after install
Flex Coupling
Coupling aligned
Coupling gap checked
Coupling lubricated
Accessories (if equipped)
Damper opens and closes correctly
Guards are installed and do not rub
Shaft seal is tight
Heat slinger is tight
Isolation (if equipped)
Springs are adjusted per manufacturers’
specification
Flex joints allow movement
Electrical conduit allows movement
Electrical
Motor wired for proper voltage
Motor is grounded
Starter functions properly (if equipped)
VFD functions properly (if equipped)
Leads are properly insulated per NEC
guidelines
Accessories are wired and installed per
manufacturers’ instructions
Start-Up
Bump start unit only to slowly rotate wheel
Verify wheel direction� Re-wire if necessary
Check for excess vibration and listen for
abnormal noise� Refer to AMCA guidelines table
for vibration limits�
Final check to insure everything runs properly
(no abnormal smell, sounds or vibrations)�
Unit Information
Serial number Model information
Mark number
Completed by ________________________
Date completed ______________________
Notices
Electrical safety
Lock out where necessary
