Ceiling Exhaust Fans 7
Maintenance
ATTENTION
Disconnect power source before working on unit.
Routine maintenance must be performed annually.
IMPORTANT
1. Never use gasoline, benzene, thinner or any other
such chemicals for cleaning the ventilating fan.
2. Do not immerse motor in water when cleaning.
3. Do not soak parts in water over 140°F (60°C).
Cleaning
1. Remove grille. Squeeze mounting spring and pull
down carefully. See Fig. 11.
2. Clean grille. Do not put into hot water. Use non-
abrasive kitchen detergent, wipe dry with clean cloth.
See Fig. 12.
3. Remove dust and dirt from fan body using a vacuum
cleaner. See Fig. 13.
4. Using a cloth dampened with kitchen detergent,
remove any dirt from fan body. Wipe dry with clean
cloth. See Fig. 14.
5. Ensure grille is dry and reinstall onto the fan.
Mounting
spring
Slot
Grille
Fig. 11
Fig. 12
Fig. 13
Fig. 14
