Greenheck QEI-L - Mounting Configurations; Belt Drive Mounting Options

12
Belt Drive Mounting
Configurations
Universal Mounting
QEI-I/IImodelssizes9-27andallQEI-Lmodelscanbe
mountedhorizontallyorvertically.Foreaseofinstallation,
eightmountingbracketsareweldedoneachfan.These
eightbracketsalongwithstandardmountingsupports
provideforGreenheck’sUniversalMountingSystem.
Motorpositionsareviewedfromthedischargeend.
Fig.1 HorizontalBaseMount
 Eachfanisshippedasstandardinthisarrangement.
 Motorat“A”position(12o’clock)isstandard.
Fig.2 HorizontalBaseMountwithmotorat“C”or“G”
position(3or9o’clock).Asetofoptionalmounting
railsarerecommendedforthisinstallation.
Fig.3 HorizontalCeilingHung
 Inthisinstallationthesupportscanbepositionedfor
mountingthemotorat“A”or“E”(12or6o’clock).
Fig.4 HorizontalCeilingHungwithmotorat“C”or“G”(3
or9o’clock).Asetofoptionalmountingrailsare
recommendedforthisinstallation.
Fig.5 VerticalMount
 UniversalQEIfanscanbemountedvertically(ceiling
hungorbasemount)foreitherupwardordownward
airflow.Optionalmountingrailsaresuggestedfor
anyverticalinstallation.
QEI-I/II Sizes 9-27 and all QEI-L
QEI-I/II Sizes 30-60
QEI-I/IImodels30-60areavailableinhorizontalandverticalmountingconfigurations.
Lifting lugs are provided on horizontal fans for ease of installation. Vertical units
should be lifted by the mounting brackets.
Horizontal Mounting
Horizontalmountingconfigurations,basemountorceilinghung,areprovidedwithan
identicalsupport.Themountingconfigurationcanbechangedbetweenbasemount
orceilinghunginthefield.Themotorpositioncanalsobefieldrotatedtoanyofthe
shownpositions.Motorpositionsareviewedfromthedischargeend.
BaseMount: Rigidsteelbaseprovidesstablemountingtofloorforthehousing.
 MotorPositions:A,B,C,GandH
CeilingHung: Suspendthefanhorizontallyfromtheceiling.
 MotorPositions:A,C,D,E,FandG
MountingrailsarerecommendedforhorizontalinstallationswithB,C,D,F,GandH
motorpositions.
Vertical Mounting
Verticalmountingconfigurations,upblastordownblast,areprovidedwithheavydutysteelbracketsweldedto
bothends.Thesebracketspermiteitherfloororceilingmountingonthesameunit.Optionalmountingrailsare
suggestedforanyverticalinstallationforsizes9-27.
Optional
MountingRails
Fig. 1
Fig. 3
Fig. 5
VerticalCeilingHung
VerticalBaseMount
Fig. 2
Optional
Mounting
Rails
Fig. 4
Optional
Mounting
Rails
Horizontal-BaseMount
Horizontal-CeilingHung
A
B
C
H
G
A
G
F
E
D
C
