16
Model SP-A
Premium Ceiling Fan
Model SP-A Dimensions
Model A B C D E
Designer
Grille*
Decorative
Grille
Unit
Weight
50, 70, 90
13
1
⁄4
(337)
10
5
⁄8
(270)
9
(229)
6
(152)
14
7
⁄8 x 13
1
⁄4
(378 x 337)
15
1
⁄4
(387) sq.
12
(5)
110, 125, 190
13
1
⁄4
(337)
10
5
⁄8
(270)
9
(229)
8
(203)
6
(152)
17
(8)
200, 250, 290,
390
14
(356)
11
7
⁄8
(302)
11
1
⁄4
(286)
8
(203)
8
(203)
24
(11)
410, 510
18
(457)
14
3
⁄8
(365)
14
1
⁄2
(368)
8
(203)
8
(203)
19
3
⁄8 x 16
3
⁄8
(492 x 416)
—
31
(14)
700
23
5
⁄8
(600)
11
5
⁄8
(295)
11
5
⁄8
(295)
19
1
⁄2
(495)
8
(203)
25
1
⁄8 x 13
1
⁄2
(638 x 343)
34
(15)
710, 780
18
(457)
14
3
⁄8
(365)
14
1
⁄2
(368)
10
(254)
8
(203)
19
3
⁄8 x 16
3
⁄8
(492 x 416)
34
(15)
900, 1050,
1410, 1550
23
3
⁄4
(603)
14
3
⁄8
(365)
14
1
⁄2
(368)
18
3
⁄4
(476)
8
(203)
25 x 16
3
⁄8
(635 x 416)
56
(25)
All dimensions are in inches (millimeters) and weight in pounds (kilograms).
Outlet connection width is 1 in. (25 mm) - Mounting bracket width is 1½ in. (38 mm).
For complete dimensional information, see CAPS submittal drawings.
* Sizes 410 and larger have an aluminum grille as standard.
A
B
C
D
E
A
B
C
D
E
Model
Energy
Star
RPM Amps* Watts
CFM / Static Pressure in Inches wg
0 0.1 0.125 0.25 0.375 0.5 0.625 0.75 0.875 1
SP-A50
2, 3, 5
700 0.31 18.3
CFM 76 51 48 31
Sones 0.5 0.7 0.8 1.3
SP-A70
2, 3, 5
850 0.27 20.2
CFM 83 70 67 42
Sones 0.8 0.8 0.8 1.6
SP-A90
2, 3, 5
900 0.34 29.4
CFM 99 88 84 61 25
Sones 0.8 1.0 0.9 1.2 1.4
SP-A110
2, 3, 4, 5, 6
950 0.58 48.7
CFM 119 110 106 88
Sones 0.8 0.8 1.0 1.1
SP-A125
2, 3, 5, 6
1100 0.62 52.5
CFM 135 123 121 104
Sones 0.9 1.2 1.3 1.3
SP-A190
2, 3, 4, 5, 6
1400 1.30 113
CFM 216 197 192 167 133
Sones 2.5 2.5 2.5 2.5 2.5
SP-A200
2, 3, 5
900 0.43 48.2
CFM 247 225 220 196 172 142 105 67
Sones 1.4 2.0 2.0 2.5 3.0 3.5 3.5 4.0
SP-A250
2, 3, 5
1000 0.77 83.1
CFM 272 251 246 227 210 185 157 119
Sones 2.5 2.5 2.5 2.5 3.5 4.0 4.0 4.0
SP-A290
2, 3, 4, 5
1050 0.72 80.7
CFM 315 293 287 257 231 207 175 124
Sones 2.5 2.5 2.5 3.0 3.0 3.5 3.5 4.5
SP-A390
2, 3, 4, 5
1350 1.34 135
CFM 410 395 391 368 345 325 307 279
Sones 4.5 4.5 4.5 4.5 5.0 5.0 5.5 5.5
SP-A410
3
1000 1.74 121
CFM 443 413 405 351 306
Sones 3.5 3.0 3.0 3.0 3.5
SP-A510
3, 4
1070 3.30 224
CFM 557 512 501 439 392 325
Sones 5.0 4.5 4.5 4.5 4.5 4.0
SP-A700
3
1100 3.20 350
CFM 757 730 723 700 679 649 613 560 494 396
Sones 5.0 5.0 5.0 5.5 5.5 6.0 6.0 6.5 6.5 6.5
SP-A710
3
1080 4.40 285
CFM 752 714 701 653 588 486 320
Sones 6.0 6.0 6.0 6.0 6.0 5.5 5.5
SP-A780
3, 4
1600 3.30 348
CFM 812 782 775 741 704 665 625 581
Sones 8.5 8.5 8.5 8.0 8.0 8.0 8.0 8.0
SP-A900
3
950 4.00 285
CFM 955 907 896 841 773 701
Sones 4.0 5.0 5.0 5.0 5.0 5.0
SP-A1050
3, 4
1095 6.30 420
CFM 1125 1059 1043 964 885 796 662
Sones 6.0 6.0 6.0 6.0 5.5 5.5 5.5
SP-A1410
3
1450 7.40 786
CFM 1455 1415 1404 1353 1307 1262 1218 1174
Sones 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0
SP-A1550
3, 4
1610 8.60 818
CFM 1607 1558 1558 1506 1449 1407 1369 1323
Sones 10.5 10.0 10.0 10.0 10.0 10.5 11.5 13.0
2 Available with light
3 Available with CRD - Ceiling Radiation Damper
4 Also available with 50 Hz motors
(See page 20 for performance)
5 UL Listed for use above tubs.
6 Available with 277 volt motor.
Performance certified is for model SP exhaust for installation type B: Free inlet, Ducted outlet. Performance ratings include the effects of an inlet grille and backdraft
damper. Speed (rpm) shown is nominal. Performance is based on actual speed of test. The sound ratings shown are loudness values in spherical fan sones at 5 ft (1.5m)
in a spherical free field calculated per Annex B of AMCA 311. Values shown are for installation type B: free inlet spherical fan sone levels.
SP-A 110-510,
710, 780
SP-A 700,
900-1550
*Note: Amp draw is approximate and may vary based on motor manufacturer.
B
C
A
E
D
3
15
/16
SP-A 50-90
