Printed in the USA
Greenlee Textron / Subsidiary of Textron Inc.
4455 Boeing Drive, Rockford, IL 61109-2988 USA
Customer Service (International): 815/397-7070 • Fax: 815/397-9247
Customer Service (North America): 800/435-0786 • USA Fax: 800/451-2632, 815/397-1865
Canada Fax: 800/524-2853
www.greenlee.textron.com
Wiring Connections for Strain Gage Monitor
6-Pin Receptacle Wire Color Monitor Connection
Pin 1 Red TB2 2
Pin 2 Green TB2 6
Pin 3 White TB2 7
Pin 4 Black TB2 1
Pin 5 - -
Pin 6 - -
Phone Jack Unit Wire Color Monitor Connection
Positive Red TB1 10
Ground Black TB1 12
Power Connections Wire Color Monitor
Monitor Wire Unit Black TB1 7
Neutral Wire Unit White TB1 8
Ground Wire Unit Green TB1 9
