Greenlee DM-50 - Identification; Display Icons; Symbols on the Unit

DM-50 • DM-55
7
Identification
1. Display
2. Selector to select a
function or turn
power off
3. Thermocouple input
for K-type thermo-
couple (DM-55 only)
4. Permanently
attached test leads
and probes
Display Icons
5. HV 200.0 V or 300 V AC
or DC range selected
(DM-50 only)
6. – Polarity
7. Low battery
Symbols on the Unit
Warning—Read the instruction manual
Battery
Double insulation
3
4
2
1
5
6
7
