GreenTech GT1500 User Manual

Page 10
Disassembly / Assembly Cont.
Assembly
You will need a #1 PHILLIPS SCREWDRIVER.
WARNING! Do not operate the unit unless
the following are properly installed: PCO
CELL, PURIFICATION PLATE, REAR FILTER
ASSEMBLY (with all three pieces in place), and
the REAR COVER.
CAUTION! The unit should be powered off and
the POWER CORD should be disconnected
whenever cleaning/disassembling/reassembling/
servicing.
1. Installing the FRONT GRILLE:
(a) Gently put the FRONT GRILLE in place
on the front of the unit, being careful not to
damage the IONIZATION NEEDLE at the left
center of the front of the unit.
(b) Insert the four FRONT GRILLE SCREWS
one at a time until they are in place, but not
tight. After all four FRONT GRILLE SCREWS
are in place tighten them carefully.
2. Installing the PCO CELL:
(a) Gently slide the PCO CELL - warning side
facing towards you - into its slot and push
until it locks into place.
(b) Align the PCO CELL POWER
CONNECTOR to the PCO CELL POWER
CONNECTOR OUTLET and insert gently until
the tabs at the left and right of the PCO CELL
POWER CONNECTOR lock into place.
3. Installing The PURIFICATION PLATE:
(a) Slide the PURIFCATION PLATE into its
slot until it snaps into place.
(b) Align the PURIFICATION PLATE POWER
CONNECTOR to the PURIFICATION PLATE
POWER CONNECTOR OUTLET and insert
gently until the tabs at the left and right lock
into place.
4. Installing the FILTER ASSEMBLY:
(a) Place each of the FILTER ASSEMBLIES
into their slots on the sides with the solid
framed side facing out.
5. Installing the REAR COVER:
(a) Place the REAR COVER into place with the
hinges along the bottom in between the hinges
of the machine.
(b) Push the REAR COVER into place until
the tab at the top snaps into place.
6. Installing the POWER CORD:
(a) Insert the POWER ADAPTER PLUG into
the rear of the unit.
(b) Ensure the POWER CORD is properly
connected to the POWER ADAPTER
(b) Insert the POWER PLUG into a wall
outlet.
7. Turn the unit ON. Ensure that the unit’s
settings are adjusted to suit the environment
(See “OPERATIONS”).
