GreenTech GT1500 User Manual

Page 9
Copyright © 2011 GreenTech Environmental | All Rights Reserved
Disassembly / Assembly
DISASSEMBLY:
You will need a #1 PHILLIPS SCREWDRIVER.
WARNING! Do not operate the unit unless
the following are properly installed: PCO
CELL, PURIFICATION PLATE, REAR FILTER
ASSEMBLY (with all three pieces in place), and
the REAR COVER.
CAUTION! The unit should be powered off and
the POWER CORD should be disconnected
whenever cleaning/disassembling/reassembling/
servicing.
1. Turn the unit off. (See “CONTROLS”)
2. Removing The Power Cord:
(a) Unplug POWER CORD from wall outlet.
(b) Remove POWER ADAPTER PLUG from
rear of unit.
3. Clean the exterior of the unit if necessary (See
“CLEANING: UNIT EXTERIOR”).
4. Removing The Rear Cover:
(a) Begin by unplugging the POWER
ADAPTER PLUG from the back of the unit.
(b) Press down on the tab above the POWER
ADAPTER and pull back on the REAR
COVER.
5. Removing The Filter Assembly:
(a) After removing the REAR COVER slide
each of the FILTER ASSEMBLIES straight
out.
6. Removing The Purication Plate:
(a) Locate the PURIFICATION PLATE
CONNECTOR on the right rear of the unit.
Squeeze the tabs on the left and right and
gently pull free.
(b) Grasp the PURIFICATION PLATE
pressing both latches towards the middle and
gently pull the PURIFICATION PLATE out of
the grooves on the sides. Clean if necessary
(See “CLEANING: PURIFICATION PLATE”)
and set the PURIFICATION PLATE aside.
7. Removing The PCO Cell:
(a) Locate the PCO CELL POWER
CONNECTOR on the right of the rear of the
unit. Squeeze the tabs on the left and right of
the PCO CELL POWER CONNECTOR and
gently pull free.
(b) Gently slide the PCO CELL out of the unit.
Clean if necessary (See “CLEANING: PCO
CELL”) and set the PCO Cell aside.
8. Clean the interior of the unit if necessary (See
“CLEANING: UNIT INTERIOR”).
9. Removing The Front Grille:
(a) Locate the four FRONT GRILLE SCREWS
in the four corners of the FRONT GRILLE.
Using your SCREWDRIVER, carefully remove
the four FRONT GRILLE SCREWS. Place the
FRONT GRILLE SCREWS where you will nd
them easily during reassembly.
(b) Remove the FRONT GRILLE carefully
to ensure that the IONIZATION NEEDLE
(in the left center of the front of the unit) is
not damaged. Clean the FRONT GRILLE if
necessary (using compressed air, vacuum
cleaner, a damp cloth, or warm soapy water)
and set the FRONT GRILLE aside. Clean
the IONIZATION NEEDLE if necessary (See
“CLEANING: IONIZATION NEEDLE”).
