32
PARTS LIST
ITEM NO. PART NO. DESCRIPTION QTY
1 31104488 Upper handle assy. 1
2 33305469-3 Bail switch 1
3 31110487 Motor engagement box 1
4 3220439 Lock nut 1
5 33323250 Stop sheet 1
6 32208250 Screw M5x30 1
7 33302463-4 Lower handle 1
8 34103466-3 Cam lock bracket 2
9 31103487 Cam lock assy. 2
9-1 32901466 Pin 1
9-2 34102466-3 Cam lock handle 1
9-3 33201466 Cam lock bolt 1
10 3410835-20 Handle knob 2
11 3411135 Cord guide 1
12 34106467-1 Knob 2
13 3220435 Screw 6
14 33905470 Spring 1
15 33904470 Spring 1
16 33904470 Axle 1
17 34105488 40V handle 1
18 34103488 Battery door 1
19 34102488 Battery housing 1
20 34106976 Insert block 1
21 34104488 40V battery holder 1
22 32210302A Screw 2
23 31201470 Key 1
24 34101487 Motor cover 1
25 3220245 Screw 4
26 34107470 Key holder 1
27 36502487 Cord assy. 1
28 32202301A Screw 2
29 3220999 Screw 4
30 3220537 Lock nut M6 5
31 36101487 Motor 1
32 32208261 Nut M8 3
33 34105467-1 Motor holder 1
34 3330226 Washer 3
35 32205227 Bolt M6×18 3
36 3220406 Bolt M8×16 2
37 31106250-3 Motor switch cover 2
