12
ASSEMBLY
CONNECTING HIGH PRESSURE HOSE TO TRIGGER HANDLE
(See Figure 4.)
• Connect the high pressure hose to the trigger ha ndle.
Fig. 4
Fig. 5
(
See Figure 5.)
•
ASSEMBLING WAND TO PRESSURE WASHER GUN
Installing Wand to Pressure Washer Gun
Insert the male bayonet end(1) of the wand into the female bayonet outlet(3)firmly .
While pushing in the wand firmly ,turn clockwise(2)until tabs lock into place to
ensure a leak-free connection .
