GREENWORKSTOOLS.EU
22
EN
Maintenance
REPLACING THE BATTERY
WARNING! Press the STOP button and remove the safety
key before replacing batteries and wear protective gloves.
CAUTION: Use only original replacement parts.
Turn the mower upside down and remove the four Torx T20 screws and
remove the battery cover.
Disconnect the battery terminal connector.
Lift the battery straight out.
Insert the new battery in slot 1 (the rear slot).
Connect the battery terminal connector to the new battery.
Put the battery cover back into place and insert and tighten the four Torx
T20 screws.
Discard the old battery in accordance with local
environmental regulations.
