1 DESCRIPTION
1.1 PURPOSE
This machine is used to cut grass, light weeds, and other
similar vegetation at or around ground level. The cutting
plane must be approximately parallel to the ground surface.
You cannot use the machine to cut or chop hedges, shrubs,
bushes, flowers and compost.
1.2
OVERVIEW
Figure 1 - 16
.
1
Trigger
2
Lock-out button
3
Upper shaft
4
Auxiliary handle
5
Middle shaft
6
Lower shaft
7
Guard
8
Trimmer head
9
Release button
10
Positioning hole
11
Knob
12
Bolt
13
Battery release button
14
Cut-off blade
15
Spool retainer button
16
Spool cover
17
Tab
18
Spool
19
Hole
20
Spool housing
21
Anchor hole
22
Guide slot
A
Direction of roatation
B
Best cutting area
C
Dangerous cutting area
2 GENERAL POWER TOOL
SAFETY WARNINGS
W
ARNING
Read all safety warnings and all instructions.
Failure to
follow the warnings and instructions may r
esult in electric
shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your battery-
operated (cordless) power tool.
3 INSTALLATION
WARNING
Remove the battery pack from the machine before
installation.
WARNING
Do not use accessories that are not recommended for this
machine.
3.1 UNPACK THE MACHINE
WARNING
Make sure that you correctly assemble the machine before
use.
WARNING
•
If parts of the machine are damaged, do not use the
machine.
• If you do not have all the parts, do not operate the
machine.
•
If parts are damaged or missing, contact the service
center.
1. Open the package.
2. Read the documentation provided in the box.
3.
Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and packing material in compliance with
local regulations.
3.2 ATTACH THE GUARD
Figure 2 - 3.
WARNING
Do not touch the cut-of
f blade.
1. Remove the screw from the trimmer head with a Phillips
head screwdriver (not included).
2. Put the guard onto the trimmer head.
3.
Align the screw hole on the guard with the screw hole on
the trimmer head.
4. Tighten the screw.
3.3 ASSEMBLE THE SHAFT
Figure 4.
WARNING
Never install, remove, or adjust any part of a machine while
the battery is installed in the machine or the machine is
running.
