SPECIFICATION TABLE
Motor type AC induction motor
Motor peak 31HP
Power battery pack voltage 76.8 VDC 13.82kw/H
Controller CURTIS 1234E—6322
Max.speed 30 MPH (48.3 km/h)
Range (in Max Range mode on at ground)
75 miles (120 km) (may vary
with driving conditions, e.g., low
temperature, high speed, full load.)
On-board charger
HUAWEI 110-220 volt AC input; 86.4-
volt DC output (max)
Charge time
10-12 hours (dependent on depth of
discharge)
Main gearcase Direct drive with low-noise gears
Wheels, Drive system 4,Rear 2WD or 4WDv
Front Differential lock Electric control: switch
Multi-mode switch L/M/H (Low/Max Range/High)
Brakes
Front/Rear Hydraulic disc brake
Auto hold Axis brake, pedal-braking
Steering EPS
Suspension
Front Independent, Dual A-arm type
Rear Independent, Dual A-arm type
Dimensions
Length mm(in.) 3000 (118.1)
Wide mm(in.) 1600 (63)
Height mm(in.) 2050 (80.7)
Front tread centers mm(in.) 1300 (51.18)
Rear tread centers mm(in.) 1285 (50.59)
Wheelbase mm(in.) 1950 (75.77)
Ground
Clearance
front axle mm(in.) 355 (13.98)
rear axle mm(in.) 355 (13.98)
Turning diameter m (ft) 7.65 (25.1)
Max. rolling weight (Towing Capacity) kg (lbs.) 567 (1250)
Payload capacity kg (lbs.) 454 (1000)
Weight kg (lbs.) 795(1752.7)
