47
MAINTENANCE
Tires
WARNING
Operating your vehicle with worn tires, improperly inated tires, non-standard tires or improperly
installed tires will affect vehicle handling and could cause an accident resulting in serious injury or
death. Always follow all tire maintenance procedures as outlined in this manual and on the labels
on the vehicle. Always use GREENWORKS -approved size and type of tires for this vehicle when
replacing tires.
Tire Tread Depth
Always replace the tires when the thread depth is worn to
minimum allowable.
Checking tire ination pressure
Though the tire pressure is factory-set to the prescribed level, it naturally drops slowly in the course
of time, thus check it every day and inate as necessary.
TIRE SIZES INFLATION PRESSURE
Front: 28x9-14 100 kPa (14psi)
Rear: 28x11-14 100 kPa (14psi)
Inspect the following items occasionally for tightness, and if they’ve been loosened for maintenance
service. Do not lubricate the stud or the lug nut.
Wheel Removal
1. Apply the brakes. Set the park brake. Turn the key off.
2. Loosen the wheel nuts slightly.
3. Elevate the side of the vehicle by placing a suitable stand under the frame.
4. Remove the wheel nuts. Remove the wheel.
Wheel Installation
1. Set the park brake. Place the wheel in the correct position on the wheel hub. Be sure the
valvestem is toward the outside and rotation arrows on the tire point toward forward rotation.
WARNING
Improperly installed wheels can adversely affect tire wear and vehicle handling, which can result
in serious injury or death. Always ensure that all nuts are torqued to specication. Do not service
axle nuts that have a cotter pin installed. See your GREENWORKS dealer.
2. Attach the wheel nuts.
3. Carefully lower the vehicle to the ground.
4. Torque the wheel nuts to specification.
3mm(0.12in)
