GREER COMPANY 1918 EAST GLENWOOD PLACE SANTA ANA, CALIFORNIA 92705 PN W453201A 08/10/00
MicroGuard
®
434/500 CALIBRATION MANUAL TEL: 714) 259-9702 FAX: 714) 259-7626
9
OF
39
ERROR CODES
ERROR CODESERROR CODES
ERROR CODES
GROUP "A" ANALOG SENSORS
CODE
AAA
AAAAAA
AAA
000
NO FAULTS
001
TX0 PISTON PRESSURE TRANSDUCER
002
TX1 ROD SIDE PRESSURE TRANSDUCER
004
SENSOR 2 EXTENSION SENSOR
008
SENSOR 3 BOOM ANGLE SENSOR
016
SENSOR 4/5/6/7 SWING POTENTIOMETER
032
TEMPERATURE SENSOR
GROUP "B" INPUTS AND OUTPUTS
CODE
BB
BBBB
BB
00 NO FAULTS
01 FAULT 1 ADC FAULT (PISTON SIDE)
02 FAULT 2 ADC FAULT (ROD SIDE)
04 FAULT 4
08 FAULT 8 ATB FEED FAULT
16 FAULT 16 FRO FEED FAULT
GROUP "C" MEMORY
CODE
CC
CCCC
CC
00 NO FAULTS
01 FAULT 1 EXECUTIVE ROM
02 FAULT 2 DUTY ROM
04 FAULT 4 SCRATCHPAD RAM
08 FAULT 8 PERSONALITY ROM
16 FAULT 16 SERIAL EEPROM
