VSS 10-12
When connecting the ground wire to the truck frame, be sure to clean the contact area down
to bare metal to ensure a good contact. When a reel will not rewind, it is often due to a faulty
ground connection. Use extra care in protecting the wires from the exhaust system and any
moving parts. Avoid any sharp edges that could cut through the wire insulation.
30 Amp Circuit Breaker
Auto Reset
Diagram 1 Electrical Connections
To Next Page
