VSS 10-12
Set-Up and Assembly – Cont.
The engine oil, (SAE 10W30) gearbox oil, (SAE 80/90W) and pump oil (30W or 40W non-
detergent) were added at the factory. The oil levels are as follows:
• Pump Crankcase – On the Kappa 43, 55 and Kappa 75 pump, the oil level is visible
in the oil bowl. (See photo 5) Other pump models may be slightly different.
Photo 5 Kappa 43, 55 & 75 Pumps
• Engine– The oil level should be up to the edge of the filler hole or at least to the tip
of the dipstick when inserted without screwing it into the filler neck. (See photo 6)
See the Honda Engine Owner’s Manual.
Photo 6 Engine Oil Dipstick Photo 7 Pump Gearbox Side Plug
• Pump Gearbox– The oil level should be up to the lower edge of the side-plug hole.
Do not overfill. (See photo 7)
