GRIFOLS DG Spin - Centrifugation Chamber

DG Spin Description of the Centrifuge
4-2
7
6
10
9
8
77
66
10
99
88
Figure 2 : Rear view of the DG Spin centrifuge
(6) Main switch
(7) Fuses housing
(8) Mains cord connection
(9) Security ring housing
(10) Connection to a computer (for exclusive use of the authorised
Technical Service)
4.1.1 Centrifugation chamber
The Centrifugation chamber (Ref. (1), Figure 3) is the centrifuge area designed to
house the removable
DG Spin Head, contain any dirt caused by possible
fortuitous spillages or leaks and facilitate its cleaning.
1
2
3
11
22
33
Figure 3 : Centrifugation chamber
