GRIFOLS DG Spin - 4.1.5 Display; Remaining Centrifugation Time Information

DG Spin Description of the Centrifuge
4-5
4
1 3 2
44
11 33 22
Figure 6 : Display
(1) Centrifugation speed information
(2) Timer information
(3) Centrifugation speed units
(4) Warnings area
4.1.5.1 Remaining centrifugation time information
In normal mode, the Display shows on the right, the time remaining up to end of
centrifugation of the batch by means of a digital counter (Ref. (1), Figure 7) and a
progress bar (Ref. (2), Figure 7). The Progress bar will be filled in as the pre-
programmed time elapses.
1
2
11
22
Figure 7: Display with a centrifugation batch in execution
(1) Remaining centrifugation time
(2) Progress bar
